WMA318 - 18 Gallon Wall Mountable Flammmable Storage, Self-Close Self-Latch Safe-T-Door

SKU: WMA318
No of Shelves: 1
Dimension: 26"H x 43"W x 18"D
$ 1,285.00 $ 1,285.00

  • Cabinet Storage Size
  • Cabinet Door Style
  • Color
Complies with current OSHA regulations
Designed in accordance with specifications set forth by the NFPA
Factory Mutual Approved
  Lead Time: 5 Weeks
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Features & Specifications

Description

Wall Mounted Cabinets: Maximum storage in a compact size. Wall Mounted Cabinets will hold up to 24 gallons of flammable liquids without taking up valuable floor space. Furnished with brackets for easy wall mounting or can be placed on a bench top. Equipped with adjustable shelves which can be positioned to meet your specific needs.

Stackable Cabinets: These cabinets are designed to be used as a single cabinet, to fit on top of standard 30 gallon cabinets or on top of each other. Ideal for segregating flammables or to increase the capacity of your current cabinet.

Specifications

Item No.WMA318
Capacity 18 Gallon
Dimension (H x W x D) (in)26"H x 43"W x 18"D
No. of Doors2 Door
Door StyleSelf-Close Self-Latch Safe-T-Door
No of Shelves1 Shelf
Shipping Weight (lbs)210
Approval
Complies with current OSHA regulations, FM-Factory Mutual Approved, NFPA - Designed in accordance with specifications set forth by the National Fire Protection Association.
Warranty15 Year Limited Structural Warranty

Standard Features

All Securall cabinets are built to the highest quality specifications. Whether you are storing dangerous flammable chemicals or you need a cabinet for heavy industrial tools, we have the perfect cabinet for your needs. If you have a special situation that requires a customized design, we will welcome the opportunity to work with you to provide a safe storage solution. All cabinets comply with current OSHA regulations and are designed in accordance with the standards of NFPA Code 30. Popular models are FM Approved.

  • 18 GAUGE DOUBLE WALL CONSTRUCTION & SEAMED JOINTS

    Securall Safety Cabinets have Structurally Reinforced 18-Gauge Double Wall All Welded Construction throughout.

  • DOUBLE WALL CONSTRUCTION WITH 1 ½” AIR SPACE

    Securall cabinets have Double Wall Construction with 1 ½" Air Space throughout the cabinet design.

  • 2" DEEP LEAK PROOF SILL

    Securall cabinets are built with an OSHA compliant leak proof sill 2" Deep to prevent leakage in the event of accidental spills.

  • NON-SPARKING , 3-POINT, SELF-LATCHING DOORS

    Each Securall cabinet is outfitted with FM required Non-Sparking, 3-Point, Self-Latching door(s) for safe and complete closure every time.

  • SELF-CLOSING MECHANISM (IF INSTALLED) SEGREGATED FROM HAZARD AREA

    Securall Self Closing Cabinet - Self closing mechanism segregated from interior of cabinet and contents stored.

  • FUSIBLE LINK ASSEMBLY ON SELF-CLOSING MODELS

    Self-Closing cabinets come with Fusible Link Assembly. Link melts at 165 F for automatic closure in case of fire. Self closing mechanism segregated from hazard area.

  • STATIC GROUNDING CONNECTION

    All Securall cabinets come ready with an FM defined static ground connection, comprised of a NFPA compliant 5/16 - 18 x ½” Zinc Plated Grounding Bolt.

  • LARGE WARNING LABEL

    Securall cabinets have a Large Warning Label to identify the type of material stored within the unit. Also available in French and Spanish.

  • ADJUSTABLE LEVELING LEGS

    Securall cabinets are equipped with four adjustable Zinc Plated Leveling Legs for placement on uneven surface areas.

  • FLUSH MOUNTED LOCKING HANDLE

    All Securall safety cabinets come standard with a Flush Mounted Locking Handle for smooth finger-tip operation.

  • FULL LENGTH, HEAVY-DUTY PIANO HINGES

    Securall double-wall doors are secured to unit on full length, Heavy-Duty Piano Hinges for maximum security and limited vapor release.

Paint Color

The interior and exterior finish consists of an aliphatic polyurethane finish. This polyurethane coating has chemical properties to withstand salt spray, chemical rub, fading due to UV exposure, and other tests performed to epoxy paints. Urethane is more durable under conditions when moving items in and out of the cabinet as it resists chipping and peeling. Unless some other color is specified, cabinets will ship in designated standard color. For custom colors, customer must provide a paint chip.

Flammable & Combustible Classes

NFPA FLAMMABLE & COMBUSTIBLE CLASSES

FLAMMABLESFLASH POINTBOILING POINT
Class IA<73°F (22.8°C)<100°F (37.8°C)
Class IB<73°F (22.8°C)>=100° F
Class IC<73°F (22.8°C) and <100°F (37°C)>100° F



COMBUSTIBLESFLASH POINTBOILING POINT
Class II100° F (37.8° C) ≤ FP < 140° F (60° C)-
Class IIIA140° F (60° C) ≤ FP < 200° F (93° C)-
Class IIIB200° F (93° C) ≤ FP-

9.5.1 The volume of Class I, Class II, and Class IIIA liquids stored in an individual storage cabinet shall not exceed 120 gal (460 L).

9.5.2 The total aggregate volume of Class I, Class II, and Class IIIA liquids in a group of storage cabinets shall not exceed the maximum allowable quantity of flammable and combustible liquids per control area based on the occupancy where the cabinets are located.

* NFPA 30 Flammable and Combustible Liquids Code, 2011 Edition. Section 9.5.1, 9.5.2

FM Approved Fire Rating

Hurricane Resistant Wall Design

Bullet Resistant Test
