Features & Specifications
Description
Specifications
| Item No. | M1600T2O-FR2 |
|---|---|
| Bullet Resistant | Non Bullet Resistant Wall Design |
| Fire Rating | 2 Hrs Fire Rated |
| Dimension (H x W x D) (in) | 8'4" H x 10' W x 8' D |
| Warranty | 15 Year Limited Structural Warranty |
Standard Features
Type 2 Magazines are made for the storage of High Explosives and are made for indoor or outdoor storage placement. Per ATF regulations an indoor magazine may not hold more than 50 Lbs. of explosive materials and outdoor magazines must be built to a bullet resistant design.
Our Explosive Storage Magazines are portable and can be placed in most locations with a flat surface. These magazines are built for turn-key installation which also allows for easy relocation if needed.
Bullet Rated Magazines are quoted with (4) walls, including the door, to be Bullet Resistant will require a pre-approved variance by your local ATF field office.
Bullet Resistant Roof and Floor are available as additional options.
Type 2 Outdoor Magazine Bullet Resistant Design with Top, Floor, Sides and Doors Meets or exceeds ATF specs 27 CFR 555.11. (Pg. 75 ATF Ruling 76-18 (b)).
All Securall Magazines are designed to be Weather, Fire and Theft Resistant. Additionally, Securall is the only Magazine Manufacturer currently offering an optional upgrade of 2 hour Fire-Rated Walls. Also, our proprietary wall design has been tested and rated to withstand F-5 Tornado winds and associated impacts (Texas Tech University Wind Science and Engineering Research Center).
Paint Color
Flammable & Combustible Classes
FM Approved Fire Rating
Hurricane Resistant Wall Design
Bullet Resistant Test
Image 1 - Interior of Wall Panel (Pre Shoot) - Total Steel Thickness: 05095"
Image 2 - .308 Bullet Impact
Image 3 - .308 Bullet Casing Caught in Outer Wall
Image 4 - .308 Rounds Completely Stopped at Interior Plate
Image 5 - .308 Rounds Completely Stopped in Wall Channel
Image 6 - .308 Impacts - No Damage in Interior Wall
